Welcome to the LBX

ELECTRIC MOTOR

• Type (front)

  Permanent Magnet Synchronous Motor

• Maximum torque (Nm)

  185.0

PERFORMANCE

• Maximum speed (km/h)

  170 km/h

• Acceleration 0-100 km/h

  9.2 seconds

• Drag coefficient Cd value

  0.34

CO2 EMISSIONS

• CO2 Combined WLTP

  103 g/km

NVH PERFORMANCE

• Sound Level (Drive by)

  66.0 dB(A)

SUSPENSION

• Front suspension

  MacPherson Strut

• Rear suspension

  Torsion Beam

STEERING

• Turns (lock to lock)

  2.73

• Minimum Turning Radius - Tyre (m)

  5.2 m

WEIGHTS

• Kerb weight (kg.)

  1330 kg

CAPACITIES

• Towing capacity max. braked

  750 kg

• Fuel tank capacity

  36 l

• Luggage compartment capacity

  332

DIMENSIONS

• Length

  4190 mm

• Width

  1825 mm

• Height

  1550 mm

• Wheelbase

  2580 mm

BRAKES

• Front brakes

  Ventilated disc 1-cylinder

• Rear brakes

  Solid disc 1-cylinder

WHEELS AND TYRES

• Minimum fuel efficiency class

  B

• Minimum rolling noise level

  69 dB(A)

• Minimum wet grip class

  B

LOAD CAPACITY

• Number of seat

  5

HYBRID DRIVE

• Maximum output (bhp)

  94 DIN hp

EXTERIOR

• Towing capability, 750kg

• Acoustic glass, windscreen

• Rear bumper with hidden exhaust

• Integral roof spoiler

• Silver stainless steel moulding, side windows frame

• Black door belt moulding

• Chrome bumper and grille garnish

• Rain sensing windscreen wipers

• Manual-levelling headlights

• 3-flash lane change indicators

• Dusk sensor

• Daytime running lights (DRL), LED

• Rear combination lights, LED

• Rear fog light, LED

• Side indicator lights, integrated in door mirror

• Door mirrors, heated

• Door mirrors, electrically auto-folding

• Door mirrors, electrically adjustable

• Intelligent parking assist sensors, front and rear

• Rear wheel brake - 15" discs

• Resin moulding, wheel arches

• Ultra Violet (UV) and heat insulating tinted glass

• Headlights, single LED

• Front wheel brake - 15" discs

• Silver plated, unified grille

• Rear quarter panel, Piano Black

• Chrome plated rear badge, LBX

• Elegant atmosphere

• Front bumper, Silver ornament

• Rear bumper, Silver ornament

• Black outer mirror cover with black ornament

• Front indicator lights, LED

• Black resin rocker panel

ACTIVE SAFETY & DRIVING DYNAMICS

• Lexus Safety System +

• Pre-Collision System (PCS)

• Front pedestrian detection

• Dynamic Radar Cruise Control (DRCC), all-speed

• Traction Control (TRC)

• EV (Electric Vehicle) mode

• Electric Power Steering (EPS)

• Stabilisers

• Electric Parking Brake (EPB)

• Electronic Brake-force Distribution (EBD)

• Anti-lock Braking System (ABS)

• Hill-start Assist Control (HAC)

• Vehicle Stability Control (VSC)

• Automatic High Beam (AHB)

• Active brake lights

• Tyre Pressure Warning System (TPWS) with Auto location

• Lane Tracing Assist (LTA)

• Road Sign Assist (RSA)

• Acoustic Vehicle Alerting System (AVAS)

• Intersection Turning Assist (ITA)

• Emergency Steering Assist (ESA)

• Front cyclist detection

• Speed limiter linked to Road Sign Assist

• Front motorcyclist detection, daytime only

• Emergency Driving Stop System (EDSS)

• Proactive Driving Assist (PDA)

• Predictive Efficient Drive

• Electronically Controlled Braking-Regeneration

• Trailer Sway Control

PASSIVE SAFETY

• Child safety door lock

• Seatbelt pre-tensioners, front seats

• Seatbelt pre-tensioners, outer rear seats

• i-Size attachment, outer rear seats

• ISOFIX attachment, outer rear seats

• Curtain shield airbags

• Airbags, driver and front passenger

• Knee airbag, driver

• Side airbags, driver and front passenger

• Airbag cut-off switch, front passenger

• Audible and visual seatbelts reminder, front seats

• Audible and visual seatbelts reminder, rear seats

• Front centre airbag

SECURITY

• Anti-theft system - Alarm (horn)

• Anti-theft system - immobiliser

• Wireless door lock

AUDIO, COMMUNICATION & INFORMATION

• Steering wheel mounted controls, audio / display / phone / voice / DRCC / LTA

• Digital speedometer

• Tachometer/Hybrid system indicator

• Trip meter

• 7" colour multi-information display

• Antenna, shark fin design

• Digital Audio Broadcasting (DAB) radio

• Bluetooth® mobile phone and audio connectivity

• Parking assist monitor with on-screen guides

• Emergency Response System (eCall)

• 9.8" touchscreen display

• Smartphone integration (Wireless Apple CarPlay®, wired Android Auto™)

• Lexus Link Cloud-based Navigation

• Lexus Link Connect

• 6-speaker premium audio system

• USB port (Type-C), front centre console

• USB charging port (Type-C), front centre console

INTERIOR COMFORT & CONVENIENCE

• Steering column, manually multi-adjustable

• Tyre repair kit

• Auto door locking

• Electrically operated windows with one-touch control

• Tailgate, push button release

• Tailgate, manually operated

• Smart key

• Glovebox illumination, LED

• Luggage room light, LED

• Illuminated entry system

• Rear-view mirror, electro chromatic (auto-dimming)

• Resin scuff plates, rear doors

• Luggage cover board, manually folding

• Cup holders, front

• Storage box, front centre armrest

• Automatic air recirculation control

• Remote climate control

• Humidity sensor for climate control

• Electronic climate control, 2-zone

• Clean air filter with pollen removal and deodoriser

• Manually folding rear seat backrest, 60/40 split

• 2-way manually adjustable front headrests

• 2-way manually adjustable rear headrests

• 2-way lumbar support, driver seat

• Heated front seats

• 6-way manually adjustable driver seat

• 6-way manually adjustable front passenger seat

• 12V socket, front

• 12V socket, luggage compartment

• Push start button

• Smart start system

• e-Latch door lock system

• Ambient lighting (Single Colour)

• 3-spoke, Tahara trimmed steering wheel

• Tahara trimmed gearshift knob

• Sport front seats

• Instrument panel, Tahara

• Door panel finish, Tahara

• Tahara upholstery, front centre armrest

• Black seat belts

• Door inlays, Satin Paint

• Front centre console, Wood Grain finish

• Satin, Y-shaped embroidery with double stitch on bolsters

• Black steering wheel and gearshift knob

• Vegan Tahara upholstery, front seats

• Vegan Tahara upholstery, rear seats

• Resin scuff plates with metal insert, LEXUS inscription, front doors

• Fuel Combined WLTP

  4.5 l/100km
